ALPINE SWR-M100 MARINE SUBWOOFER
DESCRIPTION
General Features:
300W RMS/ 900W Peak
4 O Impedance
High Excursion for deep, high output bass
Infinite Baffle Design for widest application
Custom high-strength polypropylene frame
High AMplitude Multi-Roll (HAMR) Surround (Pat. Pend)
CRC Motor Structure (Patented)
Thermal Management System
Integrated Insert & Spade Terminals
Hidden Screw Mounting & Grille Design
Waterproof Rubber Mounting Gasket Included
Gasket
Design: Rubber Mounting Gasket
Tinsel Leads
Design: 16ga. Stranded Leads, Insulated
Terminals
Design: 2-Way, Insert & Quick-Connect Terminals
Layout: One Side
Frame
Design: Custom High Strength 5-Leg
Material: Injection Molded Polypropylene
Motor Structure
Configuration: Airflow Management System
Pole Geometry: Compound Radius Curve
Voice Coil
Design: 4-Layer Single Voice Coil
Material: High Temp. Copper Wire on TIL Former
Spider
Design: Progressive
Material: Nomex®
Surround
Design: High Amplitude Multi-Roll
Material: Injection Molded Sanoprene®
Diaphram
Design: 2-Piece Structural Parabolic
Material: Molded Polypropylene
SPECIFICATIONS
Dimensions
Added Volume: 0.055 cu. ft. (Reverse Mount, Magnet Out)
Displacement: 0.083ft cu. ft. (Front Mount)
Mounting Diameter: 229 mm (9-1/32”)
Mounting Depth: 144.72 mm (5-11/16”)
Power Handling
Peak Power Handling: 900 Watts
RMS Power Handling: 300 Watts
CEA-2006 Power Rating: 300 Watts
